1Inch 90° 3 x DIA BEND POLISHED 316

1" 90° 3 x DIA BEND POLISHED 316


Stock Code: 0902510
Out of Stock
£20.84

Descriptions

  • 90° bend with a radius of 3 x the tube diameter – Long sweeping bend.
  • Stocked from 1″ OD – 3″ OD in 316 Stainless Steel.
  • Closure Rings for Jacketing are available
  • Test Certification can be provided on request.

Size1" / 25.4mm OD
Grade316L
Product Group3 x D 90 Degree Bend
Bend Radius3D / 75mm
Centre To Face (mm)115mm
FinishPolished
Thickness1.5mm
