2.5" P/E 90° PRODUCT STRAINER BODY KIT - TYPE A - 316


Stock Code: 2340225
In Stock
£201.91

The 90° product strainer is designed specifically for finer filtration of product, and to remove potentially unwanted items in the product. The body is much larger than the pump protection strainer to keep back pressure and pressure drop to a minimum.

  • Designed & Manufactured by Berkeley Stainless Fittings Ltd, to the highest quality.
  • Manufactured entirely from 316L Stainless Steel.
  • 1″ OD – 6″ OD line size available.
  • Standard finish: Dull Polished O.D, Mill finish I.D – Other finishes available on request.
  • For 1″, 1.5″ & 2.5″ inlet/outlet, a concentric reducing cone will be used on a standard body.
  • Alternative ends can be welded to customers requirements – RJT, IDF, CLAMP, DIN & SMS.
  • Shut off valves can be welded to the unit.
  • 90° product strainer assembly consists of: 1 x Element, 1 x Body, 1 x Single Hinged Clamp & 1 x Lipped EPDM joint ring.
  • Elements – Perforated type & wedge wire type available to choose from – See element pages
  • We recommend ordering a replacement element to ease cleaning and to minimize line down time.
  • Jacketed & Duplex strainers can also be supplied to the customers specifications.
  • Should you require anymore information regarding our strainers – Please contact your local branch and a member of sales will be happy to assist you.
Product Group90 Degree Product Body Type A
Size2.5"
Grade316
Seal MaterialEPDM Body Seal
FinishDull Polished OD
Additional Info3" OD Body Coned to 2.5" OD
