2.5Inch RJT COMPLETE UNION 316 NITRILE SEAL

2.5" RJT COMPLETE UNION 316 NITRILE SEAL


Stock Code: 0102825
In Stock
£12.42

This complete RJT union provides a secure, hygienic connection for stainless steel tube systems, commonly used in dairy, food, beverage, and pharmaceutical processing. Supplied fully assembled with a nitrile joint ring, it offers reliable sealing and ease of maintenance.


Components Included

  • RJT Male Part – Machined from 316 stainless steel
  • Pressed Liner – 316 stainless steel - smooth bore insert for hygienic flow
  • Hex Nut – 304 stainless steel
  • Nitrile “O” Ring – Standard seal with good oil and chemical resistance

Specifications

  • Size range: Available from 1″ to 4″ OD
  • Material: 316 stainless steel (male and liner), 304 stainless steel (nut)
  • Finish: Dull polished
  • Seal: Nitrile rubber, 70–75 Shore A hardness

Applications

  • Ideal for hygienic systems requiring frequent disassembly
  • Compatible with CIP (Clean-In-Place) and manual cleaning routines


Disclaimer: It is the customer’s responsibility to ensure that the selected seal material is chemically compatible with their specific process media and operating conditions.




Size2.5" / 63.5mm OD
Grade304 Nut - 316L Wetted Parts
StandardBS4825 PT5
Seal MaterialNitrile
Seal ColourBlack
